Portable oxygen concentrator GCE Healthcare Zen-O
Zen-O™ portable oxygen concentrator is designed to enable patients with respiratory disorders such as chronic obstructive pulmonary disease (COPD), to better manage their oxygen therapy within and outside their homes.
Zen- O™ portable oxygen concentrator delivers freedom and peace of mind to patients by providing mobile oxygen on demand.
Zen-O™ weighs just 4.66 kg and can deliver up to 2 litres per minute of oxygen in either pulse or continuous flow. Zen-O is supplied with variety of accessories, including a carry bag and a pull cart for increased mobility.
Zen-O’s practical and robust design offers greater operational efficiency and low cost of ownership for home oxygen providers.
Zen-O™ is designed with easy to replace sieve bed. The sieve bed can be replaced in the field using simple tools in under 5 minutes, saving time and money.
Zen-O™ is produced in the UK following GCE’s investment in a new manufacturing and innovation centre.
Notice: the cellphone present in the images is represented for purely comparative purposes and has nothing to do with the product and is not included in the offer.
Zen-O™ uses advanced technology to adjust the amount of oxygen delivered in response to a patient’s breath rate and automatically increases the amount when the patient needs it most – such as walking uphill.
FEATURES AND BENEFITS
Dual mode
Zen-O™ portable oxygen concentrator can deliver up to 2 litres of oxygen in either pulse or continuous flow.
Easy to use
Zen-O™ is simple to use with clear button operation and LCD panel.
Zen-O™ portable oxygen concentrator is manufactured in the UK to high standards. GCE has locations Latin America, China and multiple warehouses across Europe. Our strategic partners in North America and Africa help us ensure accessories and spare parts are readily available to our customers.
Field replaceable sieve bed
Zen-O’s practical design makes it easy for home oxygen providers to replace the sieve bed in under
5 minutes using simple tools.
Visual and audio alarms
Zen-O™ has various audible and visual alarms to prompt the user of a required action. Some alarms include low battery, service required, and no breath detected.
Technical information
Zen-O™ is manufactured to meet the exacting standards of the European Medical Device Directive. GCE Healthcare ensures that our products undergo rigorous safety and quality checks before they reach our customers. Below is the technical information for the
Zen-O™ portable oxygen concentrator.
| Size (W×D×H): | 212 mm × 168 mm × 313 mm
(8.3" × 6.6" ×12.3") |
| Weight: | 4.66 kg with one 12 cell battery |
| Power requirements: | AC adaptor: 100-240V AC(+/- 10%) 50-60 Hz in,
24V DC, 6.25A out
DC adaptor: 11.5 - 16V DC in, 19V, 7.9A out |
| Purity: | 87% - 96% at all settings |
| Maximum oxygen discharge pressure: | 20.5 psi |
| Inspiratory trigger sensitivity: | -0.12cm/H20 |
| Humidity range: | 5% to 93% ± 2% non-condensing |
| Temperature: | |
| Operation: | 5°C (41°F) and 40°C (104°F) |
| Storage: | -20°C (-4°F) and 60°C (140°F) |
| Setting: | Adjustable in 0.5 increments from 1.0 to 6.0 in pulse
mode and from 0.5 to 2.0 in continuous mode |
| Noise level: | 38 dB(A) tested to Prüfmethode
14-1 03/2007 MDS-Hi*
42 dB(A) tested to ISO 3744* |
| Alarm types: | Low oxygen purity
No breath detected
Low battery
Service required |
| Battery duration: | Approx. 4 hours with a single battery or 8 hours
with 2 batteries at 18 BPM |
*At pulse setting 2.
| Item No. | Description |
| RS-00502-G-S | Zen-O™ concentrator 12 cell |
| RS-00502-G-D | Zen-O™ concentrator 2 battery package |
| RS-00501 | Zen-O™ battery 12 cell |
| RS-00509 | Zen-O™ carry bag |
| RS-00507 | Zen-O™ cart |
| RS-00508 | Zen-O™ DC adapter |
| RS-00511 | POC filter wrench |
| RS-00512 | POC cannula filter pk of 10 |
| RS-00520 | Zen-O™ AC power supply w/EU cord |
| RS-00521 | Zen-O™ AC power supply w/UK cord |
| RS-00522 | Zen-O™ AC power supply w/US cord |
Each Zen-O™ device is supplied with a carry bag, battery, AC/DC power cables and a pull cart.
